K SINGLE IMPELLER

Single-impeller centrifugal pump suitable for domestic, civil, industrial and agricultural systems, and for decanting, mixing and irrigation uses.

Operating range: from 1,8 to 96 m3/h, with head up to 62 metres.

Maximum operating pressure: K 20/41, K 30/70, K 30/100, K 36/100, K 12/200, K 14/400 : 6 bar (600 kPa), K 36/200, K 40/200, K 55/200, K 11/500, K 18/500, K 28/500 : 8 bar (800 kPa), K 40/400, K 50/400, K 30/800, K 40/800, K 50/800, K 20/1200, K 25/1200, K 35/1200 : 10 bar (1000 kPa)

Installation: horizontal or vertical position, provided that the motor is always above the pump.

Liquid temperature range: K 20/41, K 30/70, K 30/100, K 36/100, K 12/200, K 36/200, K 40/200 : from -10 °C to +50 °C.
Remainder of the range: from -15 °C to +110 °C.
